Gossen M530G - Mavospec Lite-ASM - class B - DIN 5032

Gossen M530 MAVOSPEC Lite-ASM | Class B DIN 5032 high quality handheld spectrometer

Special ASM edition includes a package of useful accessories, exclusively only available from Asmetec

Specification
The MAVOSPEC Lite is a high-quality, miniaturized spectrometer for routine daily measurement of all conventional and modern light sources such as LEDs and OLEDs. All characteristic measured quantities such as illuminance, correlated color temperature, , color rendering index according CIE 13.3 as well as color coordinates in accordance with various CIE standards, spectral power distribution, peak wavelength and dominant wavelength are determined for the measured spectrum and displayed such that they can be understood by experts as well as laypersons.

The Mavospec Lite provides you with certified safety – for light which ideally fulfils your requirements in every respect. Regardless of the lighting situation – from private residential or professional, right on up to industrial – compliance with specified values and standards, as well as consideration of quantitative and qualitative requirements, are decisive in terms of the achieved lighting effect. The Mavospec Lite assesses your light and delivers information covering all relevant factors – certified and documented for more safety from planning to commissioning.

THE MAVOSPEC LITE PROVIDES SUPPORT FOR LIGHTING DESIGN
From selecting and matching various light sources all the way through to checking the results and approving the installation, the Mavospec Lite provides you with all important values.

THE MAVOSPEC LITE PROACTIVELY DETECTS ELECTRICAL INSTALLATION PROBLEMS
By proactively assessing the light quality of delivered lighting fixtures, you can avoid subsequent complaints in advance and ensure smooth approval procedures by quickly checking the lighting installation at the touch of a button.

THE MAVOSPEC LITE ENSURES STANDARDS-COMPLIANT WORKSTATIONS
Defined, precisely specified lighting quality is stipulated in the standards for workstations. These requirements are especially strict in, for example, the medical engineering, cosmetics and chem - icals industries. The Mavospec Lite provides you with all of the decisive values simply and quickly – for certified safe light.

THE MAVOSPEC LITE MAKES PUBLIC PLACES SAFE
Changeovers to LED lighting and new installations in public areas – lighting has to ensure safety and comply with the standards in these applications.
The Mavospec Lite supports you in your testing process and provides you with certified, documented security.

Testing Light Safely and Effectively – Anytime, Anywhere
Regardless of which kind of light you want to test – the Mavospec Lite delivers all decisive measured values with certified precision by simply pressing a key. Thanks to its simple operation and fast, efficient results documentation, light can be tested by any user with the Mavospec Lite. And our outstanding service in Germany assures that you can quickly get back to measuring with absolute precision when calibration is required, or in the event of repairs. The Mavospec Lite provides you with perfection and safety – day after day, in any application and with all light sources.

Photometry:
Applications: Daylight, LEDs, Halogen, CFL etc in the spectral range from 380 nm to 780 nm,
Illuminance 10 lx to 100.000 lx
Color temperature CCT  1600K to 50.000K
Color rendering index CRI Ra, Re, R1 ~ R15
Gamut Area Index GAI
Chromaticity coordinates acc. to CIE 1931, CIE 1976, CIE 1960
Configurable measured dispaly
Selectabe units of measure lx / °C - fc / °F

Please see technical data sheets for more information in our downblod area.



Special ASM accessories included free of charge:
Clean room wiper, clean room gloves, Tough-Light-Pen, 5 year free of charge compare check

Scope of delivery:
Nylon pouch, rechargeable battery, USB cable, power charger, carrying strap, 4 GB micro SD card, instructions, ASM special accessories


Optional Accessories:
Replacement Rechargeable Battery V070A Li-Ion 3,7 V, 890mAh
DAkkS Calibration certificate
